Brand Name	Lewden
Colour	white
Material	Steel
Manufacturer Model No	E-TPN12LW
Type	Distribution Board
Certifications Met	BS EN 61439-3:2012
Country of Origin	0.01kg
Busbar Rating	200A
Current Rating	125A
Depth	120mm
Dimensions	(H)700 mm x (W)458 mm x (D)120 mm
Guarantee	1 Year
Height	700mm
IP Rating	IP2XC
Incoming Device	Not Supplied
Mounting	Surface
Number of Outgoing Ways	12
Packaging Types	Each
Unspsc V18	39121110
Unspsc V24	39121110
Voltage Rating	230V 415V
Weight	0.01kg
Width	458mm

3-phase distribution board with optimal space for simple and safe wiring. Lock and key make it ideal for commercial and industrial installations. Compatible with Lewden 10kA MCBs and RCBOs, and can also be used with Lewden 6kA MCBs and RCBOs with the addition of a mounting kit. Removable gland plate without knockouts and DIN rail supplied.

Brand Name	Lewden
Manufacturer Model No	E-TPN12LW
Busbar Type	Fixed Busbar
Cable Entry Points	Top & Bottom
Construction Material (Electrical)	Steel
DIN Rail Supplied	DIN Rail Supplied
Max. Busbar Rating	125 A
No. of Phases	3-Phase
Product Depth	120 mm
Product Height	700 mm
Product Width	458 mm
Total No. Module Spaces When Empty	12
Total Product Weight	14.85 kg
Way	12 Way

Lewden compact and flexible board is supplied unpopulated for maximum plan flexibility. Complies to BS7681:2008 + Amendment 3:2015. Compatible with the Lewden 10kA MCB, RCBO and mains switch range. The heavy gauge robust steel construction makes it appropriate for wall mounting. Low smoke and fume powder coated finish to RAL 9003.

Brand Name	Lewden
Colour	Light Grey
Material	Steel
Manufacturer Model No	E-TPN12LW
Type	Type B Distribution Board
Certifications Met	BS7681:2008 + Amendment 3:2015
Width	458mm
Waist Size	aa55ce14gz
Number of Circuit Breakers	12
Height	700mm
Depth	120mm
Current Rating	125 A
Configured For	TP/SP Devices
