KQ miniature circuit breakers. Positive contact indication [guaranteed On/Off indication]. Trip free mechanism operates even when the toggle is locked on. Lockable in the ON or OFF position. For use in LoadCentre KQ Type A and Type B distribution boards.

Brand Name	Schneider Square D
Manufacturer Model No	SE10C132
Type	MCB
Certifications Met	BS EN 60898, BS EN 60947
Current Rating	32A
Depth	78.5mm
Dimensions	(H)85 mm x (W)18 mm x (D)78.5 mm
Guarantee	1 Year
Height	85mm
Mounting	DIN Rail
Number of Modules	1
Number of Poles	Single Pole
Outgoing Terminal Capacity	35mm ²
Packaging Types	Each
Product Range	Acti9 iKQ
Short Circuit Rating	10kA
Tripping Characteristics	C Curve
Unspsc V18	39121603
Unspsc V24	39121603
Voltage Rating	230V
Voltimum+Points	17
Weight	0.121kg
Width	18mm
